Dual Polarized Horn Antenna 15dBi Gain, 60GHz-90GHz Frequency Range

Tlhaloso e Khutšoanyane:

MT-DPHA6090-15 e tsoang ho Microtech ke kopano ea li-antenna tse nang le lihlopha tse feletseng, tse peli-polarized, tsa WR-12 tse sebetsang ka maqhubu a 60 GHz ho ea ho 90 GHz.Antenna e na le converter e kopaneng ea orthogonal mode e fanang ka ho itšehla thajana ho phahameng.MT-DPHA6090-15 e ts'ehetsa litsamaiso tsa waveguide tse otlolohileng le tse rapameng 'me e na le khatello e tloaelehileng ea 35 dB cross-polarization, phaello ea lebitso la 15 dBi bohareng ba maqhubu, 3db e tloaelehileng ea likhato tse 33 sefofaneng sa E, 3db e tloaelehileng. bophahamo ba likhato tse 33 sefofaneng sa H.Kenyelletso ho antenna ke WR-12 waveguide e nang le UG-387/UM e khoeleng flange.

Iteanye le rona Khoasolla Datasheet E teng thepeng e teng ka lebenkeleng

Lintlha tsa Sehlahisoa

Tsebo ea Antenna

Li-tag tsa Sehlahisoa

Likaroloana

● Tšebetso e Feletseng ea Band
● Polarization e habeli

● Ho Ikhetha ho Phahameng
● E entsoe Hantle-ntle 'me e Pelletsoe Khauta

Litlhaloso

MT-DPHA6090-15
Ntho	Tlhaloso	Diyuniti
Maqhubu a Range	60-90	GHz
Fumana	15	dBi
VSWR	1.3:1
Polarization	Tse peli
Ho Horizontal 3dB Beam Width	33	Likhato
E otlolohileng 3dB Bean Bophara	28	Likhato
Ho Ikhetha Boema-kepe	45	dB
Boholo	27.90*51.70	mm
Boima ba 'mele	74	g
Boholo ba Waveguide	WR-12
Tlhaloso ea Flange	UG-387/U
Body Material le Qetella	Aaluminium, Khauta

Moralo oa Kemiso

Liphetho tsa liteko

E fetileng: Dual Polarized Horn Antenna 15dBi Gain, 50GHz-75GHz Frequency Range

E 'ngoe: Antenna ea Conical Dual Polarized Horn 19dBi Typ.Fumana, 93-95GHz Frequency Range

Lerata le ka morao

Lerata le hlahisoa ke likarolo tse lahlehileng le lisebelisoa tse sebetsang ka har'a moamoheli, empa lerata le ka fetisetsoa ka lenakana ho kenyeletso ea moamoheli.Lerata la li-antenna le ka amoheloa ho tsoa tikolohong ea kantle, kapa la hlahisoa ka hare, joalo ka lerata la mocheso le bakoang ke tahlehelo ka har'a antenna ka boeona.Lerata le hlahisoang ka hare ho moamoheli le ka laoloa ho isa bohōleng bo itseng, ha lerata le amohetsoeng ke lenakana le tsoang tikolohong hangata le sa laolehe 'me le ka feta lerata la moamoheli ka boeona.Ka hona, ke habohlokoa ho bontša matla a lerata a fanoang ke antenna ho ea amohelang.

Li-antenna tse nang le maballo a maholo a pharaletseng a ka nka matla a lerata ho tsoa mehloling e mengata e fapaneng.Ho feta moo, lerata le ka amoheloa ho tloha mahlakoreng a mahlakoreng a mohlala oa mahlaseli a antenna, kapa ka lipontšo tse tsoang fatše kapa linthong tse ling tse kholo.
