Dual Polarized Horn Antenna 15dBi Gain, 75GHz-110GHz Frequency Range

Tlhaloso e Khutšoanyane:

MT-DPHA75110-15 ho tloha Microtech ke kopano ea li-antenna tsa lenaka tse tletseng lihlopha tse peli, tse peli-polarized, tsa WR-10 tse sebetsang ka maqhubu a 75 GHz ho ea ho 110 GHz.Antenna e na le converter e kopaneng ea orthogonal mode e fanang ka ho itšehla thajana ho phahameng.MT-DPHA75110-15 e ts'ehetsa litsamaiso tsa waveguide tse otlolohileng le tse rapameng 'me e na le khatello e tloaelehileng ea 40 dB cross-polarization, phaello ea lebitso la 15 dBi bohareng ba maqhubu, 3db e tloaelehileng ea likhato tse 28 sefofaneng sa E, 3db e tloaelehileng. bophahamo ba likhato tse 33 sefofaneng sa H.Kenyelletso ho antenna ke WR-10 waveguide e nang le UG-387/UM khoele flange.

Iteanye le rona Khoasolla Datasheet E teng thepeng e teng ka lebenkeleng

Lintlha tsa Sehlahisoa

Tsebo ea Antenna

Li-tag tsa Sehlahisoa

Likaroloana

● Tšebetso e Feletseng ea Band
● Polarization e habeli

● Ho Ikhetha ho Phahameng
● E entsoe Hantle-ntle 'me e Pelletsoe Khauta

Litlhaloso

MT-DPHA75110-15
Ntho	Tlhaloso	Diyuniti
Maqhubu a Range	75-110	GHz
Fumana	15	dBi
VSWR	1.4:1
Polarization	Tse peli
Ho Horizontal 3dB Beam Width	33	Likhato
E otlolohileng 3dB Bean Bophara	22	Likhato
Ho Ikhetha Boema-kepe	45	dB
Boholo	27.90*52.20	mm
Boima ba 'mele	77	g
Boholo ba Waveguide	WR-10
Tlhaloso ea Flange	UG-387/U-Mod
Body Material le Qetella	Aaluminium, Khauta

Moralo oa Kemiso

Liphetho tsa liteko

VSWR
