Waveguide Probe Antenna 8 dBi Gain, 90GHz-140GHz Frequency Range

Waveguide Probe Antenna 8 dBi Gain, 90GHz-140GHz Frequency Range E Featured Image
  • Waveguide Probe Antenna 8 dBi Gain, 90GHz-140GHz Frequency Range

Tlhaloso e Khutšoanyane:

MT-WPA8-8 ho tloha Microtech ke F-Band probe antenna e sebetsang ho tloha 90GHz ho isa 140GHz.Antenna e fana ka phaello ea lebitso la 8 dBi le likhato tse 115 tse tloaelehileng tsa bophara ba 3dB ho E-Plane le likhato tse 60 tse tloaelehileng bophara ba 3dB ho H-Plane.Antenna e tšehetsa li-waveform tsa polarized waveforms.Kenyelletso ea antenna ena ke waveguide ea WR-8 e nang le flange ea UG-387/UM.
Khoasolla Datasheet

Lintlha tsa Sehlahisoa

Tsebo ea Antenna

Li-tag tsa Sehlahisoa

Likaroloana

● WR-8 Rectangular Waveguide Interface
● Linear Polarization

● Tahlehelo e Phahameng ea ho Khutlela
● Mechine e Nepahetseng Hantle le Plate ea Khautad

Litlhaloso

MT-WPA8-8

Ntho

Tlhaloso

Diyuniti

Maqhubu a Range

90-140

GHz

Fumana

8

dBi

VSWR

 1.5:1

Polarization

Linear

Ho Horizontal 3dB Beam Width

60

Likhato

E otlolohileng 3dB Bean Bophara

115

Likhato

Boholo ba Waveguide

WR-8

Tlhaloso ea Flange

UG-387/U-Mod

Boholo

Φ19.1*25.4

mm

Boima ba 'mele

9

g

Body Material

Cu

Kalafo ea Bokaholimo

Khauta

Moralo oa Kemiso

asd

Lintlha tse Etsisoang

asd
asd
  • E fetileng:
  • E 'ngoe:

    • likarolo tsa bohlokoa le ts'ebeliso ea li-antenna tsa waveguide probe

    Directional Radiation Pattern: Li-antenna tsa Waveguide probe hangata li bonts'a mokhoa oa mahlaseli a tsela e matla haholo.Mokhoa o khethehileng oa mahlaseli o itšetlehile ka moralo le boholo ba probe ea waveguide, hammoho le makhetlo a ts'ebetso.Mahlaseli ana a tataisoang a lumella ho tsepamisa maikutlo ho nepahetseng le ho tsepamisa mohopolo oa lets'oao le fetisitsoeng kapa le amoheloang.

    Ts'ebetso ea Broadband: Li-antenna tsa Waveguide probe li ka etsoa hore li sebetse ho feta mefuta e mengata ea maqhubu.Ts'ebetso ea bandwidth e ipapisitse le moralo o ikhethileng le mekhoa ea ts'ebetso ka har'a waveguide.Ts'ebetso ea Broadband e etsa hore li-antenna tsa waveguide li lokele lits'ebetso tse hlokang ts'ireletso e pharalletseng ea maqhubu.

    Matla a Phahameng a ho Tšoara Matla: Antenna ea waveguide probe e khona ho sebetsana le maemo a phahameng a matla.Sebopeho sa waveguide se fana ka sethala se matla le se tšepahalang sa ho fetisa le ho amohela mats'oao a matla a matla a motlakase ntle le ho senyeha ho hoholo ha ts'ebetso.

    Tahlehelo e Tlase: Li-antenna tsa Waveguide probe hangata li na le tahlehelo e tlase, e bakang ts'ebetso e phahameng le tekanyo e ntlafalitsoeng ea mats'oao ho lerata.Sebopeho sa waveguide se fokotsa tahlehelo ea lets'oao bakeng sa phatlalatso e ntle le ho amoheloa ha maqhubu a motlakase.

    Moralo o kopaneng: Li-antenna tsa Waveguide probe e ka ba tsa moralo o kopaneng le o bonolo.Hangata li entsoe ka lisebelisoa tsa tšepe tse kang koporo, aluminium kapa koporo, kahoo li tšoarella ebile li na le chelete e ngata.
